TPI 621, Dual Input Differential Manometer, ±5 psi

TPI | Mfr# 621 | Item# EJH-42500-12

Replace messy U-tubes (water column manometers) and expensive pressure gauges with digital manometers.

FEATURES

Measure pressure of air and natural gas
Auto Power Off after 40 minutes
- - Adjusting appliance regulators
  - Setting delivery pressures
  - Leakage "shut-in" test
  - Regulator adjustments for pressure and lock-up tests
  - Test for leaks in low-pressure gas systems
  - Isolate difficult pressure problems on natural gas and propane systems
  - Test pressure switch operation on a 2-stage gas furnace in both positive and negative pressures
  - Static pressures in air ducts for air balancing
  - Check air filters by measuring pressure drop

Specifications
Product Type		Manometer
Unit of Measurement		mm Hg, " Hg, kPa, mBar, psi, " H₂O, mm H₂O
Resolution		0.001" H₂O
Range		±120" H₂O
Max pressure (psi)		5
Max pressure (" H2O)		120
Process connection		1/4" Barb
Accuracy		±0.5% of reading + 5 digits
Power		9V battery (included)
Model		621
Qty/ea		1
Manufacturer number		621
Brand		TPI
Display		LCD

Accessories

605 : Digital Vacuum Gauge 0/12,000 Microns
EJH-42500-18

A603 : Brass Fitting,1/8MPT - 1/4in.Barb
EJH-42500-29

TPI A774 Silicone Pressure Tubing, 6 feet
EJH-42500-30

TPI A776 Static Pressure Tip for Manometers and Combustion Analyzers
EJH-42500-31

TPI A901 Soft Carrying Case with Shoulder Strap for Manometers
EJH-42500-32

Calibrations

Innocal, NIST Calibration Service for Manometers

EJH-17090-31
