微压力计EJH-10375-37 订购编号:EJH-10375-37
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
TSI/Alnor AXD620 Micromanometer System with Data Logging Software Kit
TSI | Mfr# AXD620 | Item# EJH-10375-37
-
- Premium features make it ideal for HVAC, environmental safeguards, commissioning, process control and system balancing
- Measure differential and static pressure from -15 to +15 in. H2O (-3735 to +3735 Pa)
- Calculates and displays velocity when using a Pitot tube
- Calculates volumetric flow rate in duct from velocity and user-input duct size and shape
- Records data points in duct traverse using sampling function
- Data logging with time and date stamp
- Programmable K factors
The Alnor® AXD620 Micromanometer is a rugged, compact, comprehensive micromanometer that measures pressure. It can be used with pitot tubes to measure velocity and calculate flow rates with user–input duct size and shape.
Ideal applications include HVAC commissioning and troubleshooting, testing and balancing, Pitot tube duct traverses, static pressure measurements and differential pressure measurements.
What's Included:
Meter, hard-sided carrying case, 4 AA batteries, two 1.2m long rubber tubes, static pressure tip, LogDat2 downloading software and USB cable, manufacturer provided calibration certificate.
| Specifications | ||
| Product Type | Manometer | |
| Operating Modes | Differential/static pressure, velocity with pitot tube, sample statistics, volumetric flow rate, actual and standard velocity, variable time constant, data logging, programmable K factor | |
| Range |
Pressure: -15 to +15 in H2O -28.0 to +28.0 mm Hg -3735 to +3735 Pa Duct Size: 1 to 250 in 1 to 635 cm |
|
| Volume range | Actual range is a function of velocity, pressure, duct size and K factor | |
| Temp range | 40 to 113°F (5 to 45°C) | |
| Model | Alnor AXD620 | |
| Qty/ea | 1 | |
| Manufacturer number | AXD620 | |
| Brand | TSI | |
| Operating conditions | -4 to 140°F (-20 to 60°C) | |
| Output | USB | |
| Memory capacity | 12,700+ samples and 100 test IDs | |
| Logging intervals | Adjustable; 1 second to 1 hour | |
| Data Logging | Yes | |
| Velocity range | 250 to 15,500 ft/min (1.27 to 78.7 m/s) | |
| Dimensions | 3.3 in x 7.0 in x 1.8 in (8.4 cm x 17.8 cm x 4.4 cm) | |
| Time constant | User selectable | |
| Power | 4 AA batteries (included) | |
