Testo Multifunction Air Measurement Meter with Wireless Capability

Testo  |   Mfr# 400563 4356  |   Item# EJH-37486-01

• • Measure all-round air quality with just one meter
  • Hot-wire probe measures air velocity and temperature
  • IAQ probe measures relative humidity, CO₂, absolute pressure, and air temperature
  • Meter accepts up to two wired and three wireless probes simultaneously
  • Datalogger
This robust, reliable meter works in tough environments. The IP54 rating protects against splashes and dust. The sturdy construction protects against knocks and jars. The large illuminated display is slightly set back in the housing for better protection. The carrying strap is designed for safe transport and the magnets on the back of the unit provide a secure means of attachment to a metal object.

The easy-to-use multifunction meter provides temperature, velocity (fpm), and volume flow (cfm) measurements using the supplied hot-wire probe. A unique Indoor Air Quality (IAQ) probe provides the essential IAQ parameters of temperature, relative humidity, CO/2, and absolute pressure—making critical HVAC and IAQ measurements fast and easy. Easy-to-follow menus allow measurements to be taken and stored from different locations. The measurement values are allocated to the respective measurement locations and can be switched between user profiles. A 10,000 data point memory is standard, plus the unit can be programmed with the PC software and USB cable - making setup, data analysis, storage, and documentation easy. On-site documentation is provided by the optional IR printer.

In addition to standard probes with a wire, this meter can be easily upgraded anytime to wireless probes for use up to a distance of 65 feet (20 meters). A maximum of three wireless probes can be read and displayed by the meter, the wireless probes are available for temperature and humidity. Order the wireless upgrade kit, and either a type K thermocouple adapter or RH probe head listed to the right.
What's Included:
Hot-wire probe, IAQ probe, PC software, USB cable, three AA batteries, calibration document supplied by the manufacturer, and carrying case.

Specifications
Product Type		Combination Anemometer
Temp resolution		0.1°C/°F
Volume range		0 to 999,900 cfm
Carbon Dioxide range		0 to 10,000 ppm
Carbon Dioxide resolution		1 ppm
Carbon Dioxide accuracy		50 ppm CO2 2% of m.v. from 0 to 5000 ppm CO2 100 ppm CO2 3% of m.v. from 0 to 5001 to 10,000 ppm CO2
Absolute pressure range		600 to 1150 hPa
Absolute pressure resolution		0.1 hPa
Absolute pressure accuracy		5 hPa
Temp range		32 to 122°F (0 to 50°C)
Temp accuracy		1.0°F (0.2°C)
Qty/ea		1
RH range		0 to 100% RH
RH resolution		0.10%
RH accuracy		2 % from2 to 98 % RH
Manufacturer number		400563 4356
Brand		Testo
Air velocity range		0 to 4000 ft/min 0 to 20 m/s
Air velocity resolution		0.1
Air velocity accuracy		6 ft/m + 5% of reading (0.3 m/sec + 5% m.v.)
Display		multiline LCD
Battery life		200 hours
Dimensions		3" W x 9" H x 2-3/4" D (7.6 x 22.9 x 7.0 cm)
Power		3 AA batteries (included)

Accessories

Energizer Regular Alkaline Batteries, 1.5 V, AA, 4/pack
EJH-09376-01


Testo Wireless Upgrade Kit for Air Flow, Humidity and Temperature Meters
EJH-37486-02


Testo Temperature Probe, wireless, Type K penetration
EJH-37486-04


Testo Temperature and Humidity Probe, wireless
EJH-37486-05


Testo 0635 9535 Compact Telescopic Vane Probe; 5/8"
EJH37486-06


Testo Temperature Probe, Type K, penetration
EJH-37486-08


Testo 0635 0545 Light Intensity Probe; 0 to 100 Lux
EJH-37486-09


Testo Replacement IAQ Probe 0 to +50 °C
EJH-37486-10


Testo Repl. Hot-wire Probe 0 to +50 °C
EJH-37486-11


Testo Fast Infrared Printer with Date and Time Stamp
EJH-37486-12


Accessory Thermistor Air Probe -58 TO 300F (-50 to 148°C)
EJH-37803-56


Testo 0554 0568 Replacement Printer Paper Rolls for 92600-45; 6/Pk
EJH-92600-46


Calibrations

NIST-Traceable Calibration; Anemometers; Hot-Wire Type
EJH-17100-11
