Testo Compact Class, Mini-Vane Thermoanemometer

Testo  |   Mfr# 0560 4160  |   Item# EJH-10323-11

• • Ergonomically designed meter with compact probe for hard-to-reach areas
  • Displays air velocity and air volume (cfm) in English or metric units
  • Telescopic probe extends to 3-1/2 ft (1.1 m) long
This compact multi-function Anemometer makes airflow measurement easy and effortless. The super compact vane is designed to measure air velocity (flow) and volume flow (cfm). To calculate volume flow (cfm), just enter the air duct size (either circular diameter or rectangular length and width) and the meter automatically calculates and displays the volume flow.

Timed and multi-point mean flow calculations allow easy flow analysis, volume accumulation estimates. Min/Max values are one-button simple, while the Hold function freezes the current readings in the display for easy data recording. Meter features an auto-off function.
What's Included:
Vane probe, one 9V battery, and calibration document supplied by the manufacturer.

Specifications
Product Type		Vane Anemometer
Temp resolution		0.1°F/°C
Temp range		-4 to 122°F (-20 to 50°C)
Temp accuracy		1.5°F (0.8°C)
Qty/ea		1
Manufacturer number		0560 4160
Brand		Testo
Operating conditions		-5 to 125° F (-20 to 51° C)
Air velocity range		118 to 8000 ft/min (0.6 to 40 m/sec)
Air velocity resolution		0.1 ft/m (0.1 m/sec)
Air velocity accuracy		± 40 ft/m +1.5% of reading (±0.2 m/sec ±1.5% m.v.)
Display		multi-Line LCD
Dimensions		2 1/2"W x 7 "H x 1 1/2"D
Power		one 9 V battery (included)
Housing		ABS
