水气压计EJH-10374-55 订购编号:EJH-10374-55
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
TSI Alnor HM675 Hydronic Manometer Water Air Pressure Meter
-
- Use to balance hydronic heating and cooling systems and to check pump performance.
- Reads pressure in PSI, ft H2O, kPa, mm HG, in HG, in H2O, bar
- Reads volume in USGPM, UKGPM, m3h, l/s, l/m
- Durable splash-proof case
- Large backlit display for use in low illumination
The perfect instrument for test and balancing HVAC systems, checking pump performance, and setting balancing valves. Provides flow and BTU/hr calculations. Measure and display differential, high side, and low side pressures simultaneously without having to change hose connections or instrument valve settings. Operates on four alkaline or NiMH rechargeable batteries.HM675 kit includes: Hard carrying case, two 6.7 ft x 1⁄4 in hoses with shut-off valves, two B&G probes, two P/T gauge adapter probes, power cord, and four AA NiMH batteries.
| Specifications | ||
| Product Type | Manometer | |
| Range | 0 to 300 psi (2068 kPa) gauge differential | |
| Units | psi, in water, ft water, kPa, mm Hg, in Hg, m water, bar | |
| Resolution | 0.001 psi (0.01 kPa) | |
| Accuracy | ±1% of reading or 0.072 psi (0.5 kPa) | |
| Temp range | 40 to 113°F (5 to 45°C) | |
| Temp accuracy | ±0.5°F (0.3°C) | |
| Model | HM675 | |
| Qty/ea | 1 | |
| Brand | Alnor | |
| Display | Dot matrix LCD with backlight | |
| Dimensions | 11 1/8" x 4 3/4" x 3 1/2" (282 x 119 x 88 mm) | |
| Power | Four AA-size alkaline or NiMH; min. 12 hours continuous use | |
Accessories
Energizer Regular Alkaline Batteries, 1.5 V, AA, 4/pack
EJH-09376-01
Innocal, NIST Calibration Service for Manometers
EJH-17090-31
