天平平衡台隔离器EJH-11500-09 订购编号:EJH-11500-09
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
Speirs Robertson AMB Balance Platform, Passive Air Isolators; 60x60cm
Speirs Robertson | Mfr# AMB-60X60-SS | Item# EJH-11500-09
-
- Remove up to 90% of vibrations to improve performance of balances
- Combination of isolators and sound-deadened layer construction removes both building and surface vibrations
- Seamless pharma-grade (Ra finish 0.3) stainless steel worktops are chemical resistant and meet stringent cleaning requirements
The AMB pneumatic models incorporate tuned dampening chambers and masses to improve stability and performance. The rolling diaphragm isolators require pumped air, and are ideal for high-performance instruments such as analytical balances. The 2 Hz natural frequency of the isolators effectively removes vibrations 6 Hz and higher, common to building vibrations.
Isolators: four 2 Hz natural frequency rolling diaphragm damped isolators
Worktop material: pharma-grade stainless steel
Isolation performance: 97% at 50 Hz, 99% at 100 Hz
Working temperature: –4 to 320°F (–20 to 160°C)
| Specifications | ||
| Product Type | Antivibration Platform | |
| Capacity (kg) | 100 | |
| Capacity (lbs) | 220 | |
| Dimensions (" W) | 23-5/8 | |
| Dimensions (" H) | 2-1/8 | |
| Dimensions (" D) | 23-5/8 | |
| Platform dimensions | 60 x 60 x 5.5 cm | |
| Model | AMB-60x60 | |
| Qty/ea | 1 | |
| Brand | Speirs Robertson | |
| Manufacturer number | AMB-60X60-SS | |
