ALL PROCESSES AT A SINGLE GLANCE AT ANY TIME
The high-performance MFX_4 flow computer complies with the highest standards, allowing for flexible and reliable custody transfer measurement and blending as well as the management of processes for the handling of liquids and, in particular oil. With more than 30 years of operating experience and in excess of 15,000 installations the fourth generation combines long-standing industry know-how with state-of-the-art technologies.
Thanks to its support of various protocols and communication standards all MFX_4 systems are easy to integrate, can be configured quickly and can be serviced remotely during ongoing operations. The MFX-4 flow computer sets itself apart with its distributed architecture made up of centralised processing units and decentralised operating units, thus substantially expanding the range of possible applications.
FLEXIBILITY
a wide-ranging system family with modules for use in control rooms and external use in explosive environments, even under extreme weather conditions
SCALABILITY
use in various applications, ranging from systems with single loading stations to large, complex transfer systems
SECURITY
rigorously secure parameter access through structured system admission as part of a multi-level security approach with the archiving of all changes
AN EXCEPTIONAL SYSTEM IN DETAIL
MFX_4 CONTROLLER

The MFX_4 Controller is the centralised control unit of the MFX_4 system. It is available in two housing variants as an explosion-proof (Ex) as well as an unprotected device, whereby the functionality of the electronics is identical. Depending on the model, it can be used both in the control room and under extreme weather conditions in explosive external areas.
configurable for individual applications for blending or additivation and including an integrated PLC control system via scripting
MFX_4 TERMINAL

The MFX_4 Terminal is the human-machine interface (HMI) via which communication with the Controller, other suitable terminals or a SCADA system takes place. To ensure optimum operability, it is equipped with a configurable graphic display and is able to display all process data in various sizes and languages.
interface between the measurement device (e.g. MFX_4 Controller) and the user in the field
MFX_4 COMPACT

The MFX_4 Compact combines all functionalities of the MFX_4 Controller and MFX_4 Terminal in a single explosion-proof (Ex) housing. Thanks to its compact size, the MFX_4 Compact is also suitable for use in small systems.
