Code |
Description |
Model |
Tech. Note |
Manual |
Stock |
|
|
TN2Q2PA11A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
 |
|
|
|
|
TN2Q2PA12A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA21A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA22A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA51A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA52A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA61A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q2PA62A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA11A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA12A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA21A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA22A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA51A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA52A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA61A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q4PA62A |
Reactive power separate accessories for analogue meters - Main: three-phase 3 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA11A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA12A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA21A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA22A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA51A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA52A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA61A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q5PA62A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire unbalanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 415 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA11A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA12A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 100 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA21A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA22A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 110 V - Aux: Selfsupplied - Code completion: specify CT ratio, VT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA51A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 1 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
|
TN2Q3PA52A |
Reactive power separate accessories for analogue meters - Main: three-phase 4 wire balanced load - Format: 4 DIN module - Measure range: -Q...0...+Q - Output: 1...0...1 mA - Current: 5 A - Voltage: 400 V - Aux: Selfsupplied - Code completion: specify CT ratio and measuring range corresponding to output
|
Tesi Q |
|
|
|
|
