Contactors up to 100 A: CRNI09, CRNI12, CRNI16, CRNI22, CRNI32, CRNI38, CRNI45, CRNI63, CRNI75, CRNI85. AC and DC control

		Coil AC	Coil DC
Coil voltage		from the 24 V Ac to 400 V AC	24 V DC and 220 V DC
Rated insulation voltage V		from the 690 V to 1000 V	from the 690 V to 1000 V
Rated operating current (380 V)	AC3	from the 9 to 85 A	from the 9 to 85 A
Rated outputs of three phase motors at 50 Hz [kW]	AC3 400/380 V	from the 4 to 45	from the 4 to 45
Range of supply coil voltage		( 0,8 - 1,1 ) Us
Conventional thermal current	AC1	from the 20 to 100	from the 20 to 100
		three-pole and four-pole

Products

CRNI09-30-00-D024

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 24VDC

CRNI09-30-01-A024

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 24VAC, Auxiliary contacts: 1N/C

CRNI09-30-01-A230

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 230VAC, Auxiliary contacts: 1N/C

CRNI09-30-10-A024

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 24VAC, Auxiliary contacts: 1N/O

CRNI09-30-10-A110

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 110VAC, Auxiliary contacts: 1N/O

CRNI09-30-10-A230

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 230VAC, Auxiliary contacts: 1N/O

CRNI09-30-10-A400

Contactor, 3-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 400VAC, Auxiliary contacts: 1N/O

CRNI09-40-00-A230

Contactor, 4-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 230VAC

CRNI09-40-00-D024

Contactor, 4-poles, Ie:9 A/380V (AC3) (4 kW), Coil: 24VDC

CRNI12-30-00-D024

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 24VDC

CRNI12-30-01-A024

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 24VAC, Auxiliary contacts: 1N/C

CRNI12-30-01-A230

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 230VAC, Auxiliary contacts: 1N/C

CRNI12-30-01-A400

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 400VAC, Auxiliary contacts: 1N/C

CRNI12-30-10-A024

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 24VAC, Auxiliary contacts: 1N/O

CRNI12-30-10-A110

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 110VAC, Auxiliary contacts: 1N/O

CRNI12-30-10-A230

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 230VAC, Auxiliary contacts: 1N/O

CRNI12-30-10-A400

Contactor, 3-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 400VAC, Auxiliary contacts: 1N/O

CRNI12-40-00-A230

Contactor, 4-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 230VAC

CRNI12-40-00-D024

Contactor, 4-poles, Ie:12 A/380V (AC3) (5,5 kW), Coil: 24VDC

CRNI16-30-00-A024

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 24VAC

CRNI16-30-00-A110

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 110VAC

CRNI16-30-00-A230

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 230VAC

CRNI16-30-00-A400

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 400VAC

CRNI16-30-00-D024

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 24VDC

CRNI16-30-00-D220

Contactor, 3-poles, Ie:16 A/380V (AC3) (7,5 kW), Coil: 220VDC

CRNI22-30-00-A024

Contactor, 3-poles, Ie:22 A/380V (AC3) (11 kW), Coil: 24VAC

CRNI22-30-00-A110

Contactor, 3-poles, Ie:22 A/380V (AC3) (11 kW), Coil: 110VAC

CRNI22-30-00-A230

Contactor, 3-poles, Ie:22 A/380V (AC3) (11 kW), Coil: 230VAC

CRNI22-30-00-A400

Contactor, 3-poles, Ie:22 A/380V (AC3) (11 kW), Coil: 400VAC

CRNI22-30-00-D024

Contactor, 3-poles, Ie:22 A/380V (AC3) (11 kW), Coil: 24VDC

CRNI32-30-00-A024

Contactor, 3-poles, Ie:32 A/380V (AC3) (15 kW), Coil: 24VAC

CRNI32-30-00-A110

Contactor, 3-poles, Ie:32 A/380V (AC3) (15 kW), Coil: 110VAC

CRNI32-30-00-A230

Contactor, 3-poles, Ie:32 A/380V (AC3) (15 kW), Coil: 230VAC

CRNI32-30-00-A400

Contactor, 3-poles, Ie:32 A/380V (AC3) (15 kW), Coil: 400VAC

CRNI32-30-00-D024

Contactor, 3-poles, Ie:32 A/380V (AC3) (15 kW), Coil: 24VDC

CRNI38-30-00-A024

Contactor, 3-poles, Ie:38 A/380V (AC3) (18 kW), Coil: 24VAC

CRNI38-30-00-A110

Contactor, 3-poles, Ie:38 A/380V (AC3) (18 kW), Coil: 110VAC

CRNI38-30-00-A230

Contactor, 3-poles, Ie:38 A/380V (AC3) (18 kW), Coil: 230VAC

CRNI38-30-00-A400

Contactor, 3-poles, Ie:38 A/380V (AC3) (18 kW), Coil: 400VAC

CRNI38-30-00-D024

Stycznik 3-biegunowy. Bieguny: L1-T1, L2-T2, L3-T3. Ie: AC3 - 38 A / 380 V (18 kW), AC1 - 55 A...

CRNI45-30-22-A024

Contactor, 3-poles, Ie:45 A/380V (AC3) (22 kW), Coil: 24VAC, Auxiliary contacts:2N/O+2N/C

CRNI45-30-22-A110

Contactor, 3-poles, Ie:45 A/380V (AC3) (22 kW), Coil: 110VAC, Auxiliary contacts:2N/O+2N/C

CRNI45-30-22-A230

Contactor, 3-poles, Ie:45 A/380V (AC3) (22 kW), Coil: 230VAC, Auxiliary contacts:2N/O+2N/C

CRN45-30-22-A400

Contactor, 3-poles, Ie:45 A/380V (AC3) (22 kW), Coil: 400VAC, Auxiliary contacts:2N/O+2N/C

CRNI45-30-22-D024

Contactor, 3-poles, Ie:45 A/380V (AC3) (22 kW), Coil: 24VDC, Auxiliary contacts:2N/O+2N/C

CRNI63-30-22-A024

Contactor, 3-poles, Ie:63 A/380V (AC3) (30 kW), Coil: 24VAC, Auxiliary contacts:2N/O+2N/C

CRNI63-30-22-A110

Contactor, 3-poles, Ie:63 A/380V (AC3) (30 kW), Coil: 110VAC, Auxiliary contacts:2N/O+2N/C

CRNI63-30-22-A230

Contactor, 3-poles, Ie:63 A/380V (AC3) (30 kW), Coil: 230VAC, Auxiliary contacts:2N/O+2N/C

CRNI63-30-22-A400

Contactor, 3-poles, Ie:63 A/380V (AC3) (30 kW), Coil: 400VAC, Auxiliary contacts:2N/O+2N/C

CRNI63-30-22-D024

Contactor, 3-poles, Ie:63 A/380V (AC3) (30 kW), Coil: 24VDC, Auxiliary contacts:2N/O+2N/C

CRNI75-30-22-A024

Contactor, 3-poles, Ie:75 A/380V (AC3) (37 kW), Coil: 24VAC, Auxiliary contacts:2N/O+2N/C

CRNI75-30-22-A110

Contactor, 3-poles, Ie:75 A/380V (AC3) (37 kW), Coil: 110VAC, Auxiliary contacts:2N/O+2N/C

CRNI75-30-22-A230

Contactor, 3-poles, Ie:75 A/380V (AC3) (37 kW), Coil: 230VAC, Auxiliary contacts:2N/O+2N/C

CRNI75-30-22-A400

Contactor, 3-poles, Ie:75 A/380V (AC3) (37 kW), Coil: 400VAC, Auxiliary contacts:2N/O+2N/C

CRNI75-30-22-D024

Contactor, 3-poles, Ie:75 A/380V (AC3) (37 kW), Coil: 24VDC, Auxiliary contacts:2N/O+2N/C

CRNI85-30-22-A024

Contactor, 3-poles, Ie:85 A/380V (AC3) (45 kW), Coil: 24VAC, Auxiliary contacts:2N/O+2N/C

CRNI85-30-22-A110

Contactor, 3-poles, Ie:85 A/380V (AC3) (45 kW), Coil: 110VAC, Auxiliary contacts:2N/O+2N/C

CRNI85-30-22-A230

Contactor, 3-poles, Ie:85 A/380V (AC3) (45 kW), Coil: 230VAC, Auxiliary contacts:2N/O+2N/C

CRNI85-30-22-A400

Contactor, 3-poles, Ie:85 A/380V (AC3) (45 kW), Coil: 400VAC, Auxiliary contacts:2N/O+2N/C

CRNI85-30-22-D024

Contactor, 3-poles, Ie:85 A/380V (AC3) (45 kW), Coil: 24VDC, Auxiliary contacts:2N/O+2N/C

Accessories

CRI2A-11

Auxiliary contacts 1 N/O+1 N/Z for contactors CRNI45...85 and CRLI110...400

CRI-S44

Styki główne do CRNI85

CRI-S43

Styki główne do CRNI75

CRI-S42

Styki główne do CRNI63

CRI-S41

Styki główne do CRNI45

CRI-C24 D220

Cewka DC do CRNI75..CRNI85, DC ECONOMY CIRCUIT DC 220V

CRI-C24 D024

Cewka DC do CRNI75..CRNI85, DC ECONOMY CIRCUIT DC 24V

CRI-C23 D220

Cewka DC do CRNI45..CRNI63, ECONOMY CIRCUIT DC 220V

CRI-C23 D024

Cewka DC do CRNI45..CRNI63, ECONOMY CIRCUIT DC 24V

CRI-C22 D220

Cewka DC do CRNI32..CRNI38, DC 220V

CRI-C22 D024

Cewka DC do CRNI32..CRNI38, DC 24V

CRI-C21 D220

Cewka DC do CRNI09..CRNI22, DC 220V

CRI-C21 D024

Cewka DC do CRNI09..CRNI22, DC 24V

CRI-C14 A400

Cewka AC do CRNI75..CRNI85, AC 400/380V 50HZ, 480/460V 60HZ

CRI-C14 A230

Cewka AC do CRNI75..CRNI85, AC 230/220V 50HZ, 276/264V 60HZ

CRI-C14 A110

Cewka AC do CRNI75..CRNI85, AC 110V 50HZ/AC 132V 60HZ

CRI-C14 A024

Cewka AC do CRNI75..CRNI85, AC 24V 50HZ/AC 29V 60HZ

CRI-C13 A400

Cewka AC do CRNI45..CRNI63, AC 400/380V 50HZ, 480/460V 60HZ

CRI-C13 A230

Cewka AC do CRNI45..CRNI63, AC 230/220V 50HZ, 276/264V 60HZ

CRI-C13 A110

Cewka AC do CRNI45..CRNI63, AC 110V 50HZ/AC 132V 60HZ

CRI-C13 A024

Cewka AC do CRNI45..CRNI63, AC 24V 50HZ/AC 29V 60HZ

CRI-C12 A400

Cewka AC do CRNI32..CRNI38,AC 400/380V 50HZ, 480/460V 60HZ

CRI-C12 A230

Cewka AC do CRNI32..CRNI38, AC 230/220V 50HZ, 276/264V 60HZ

CRI-C12 A110

Cewka AC do CRNI32..CRNI38,AC 110V 50HZ/AC 132V 60HZ

CRI-C12 A024

Cewka AC do CRNI32..CRNI38,AC 24V 50HZ/AC 29V 60HZ

CRI-C11 A400

Cewka AC do CRNI09..CRNI22, AC 400/380V 50HZ, 480/460V 60HZ

CRI-C11 A230

Cewka AC do CRNI09..CRNI22, AC 230/220V 50HZ, 276/264V 60HZ

CRI-C11 A110

Cewka AC do CRNI09..CRNI22, AC 110V 50HZ/AC 132V 60HZ

CRI-C11 A024

Cewka AC do CRNI09..CRNI22, AC 24V 50HZ/AC 29V 60HZ

CRI-420

Mechanical latches for contactors CRNI45...300

CRI-410

Mechanical latches for contactors CRNI09...38

CRI20-10

Auxiliary contact 1 N/O for contactors from type CRNI09...38

CRI20-01

Auxiliary contact 1 N/C for contactors from type CRNI09...38
