Contact data |
||
Number and type of contacts |
1 C/O, 1 NO, 1 NC |
|
Contact material |
AgSnO2, AgCdO, AgCdO/Au 0,2 µm |
|
Rated / max. switching voltage |
AC |
250 V / 440 V |
Rated load (capacity) |
AC1 |
16 A / 250 V AC |
DC1 |
16 A / 24 V DC |
|
Rated current |
16 A |
|
Max. breaking capacity |
AC1 |
4 000 VA |
Coil data |
||
Rated voltage |
DC |
5 ... 110 V standard version |
Rated power consumption |
DC |
0,6 W 5 ... 60 V standard version |
0,9 W 110 V standard version |
||
Insulation |
||
Dielectric strength |
||
- between coil and contacts - contact clearance |
4 000 V AC |
|
1 000 V AC |
||
General data |
||
Electrical life resistive |
AC1 |
>105 16 A, 250 V AC |
Mechanical life (cycles) |
>3 x 107 |
|
Ambient temperature operating |
-40...+70 oC |
|
Sockets |
EC50, PW80, GD50 |
|
Accessories for sockets |
Spring wire clips |
