Number and type of contacts

2 CO, 2 NO

Contact material

AgNi, AgNi/Au 5 µm, AgSnO₂

Rated / max. switching voltage

AC

250 V / 440 V

Rated load (capacity)

AC1

8 A / 250 V AC

DC1

8 A / 24 V DC

Rated current

8 A

Max. breaking capacity

AC1

2 000 VA

Rated voltage

_{50/60 Hz} AC

12 ... 240 V

DC

3 ... 110 V

Rated power consumption

AC

0,75 VA

DC

0,4 ... 0,48 W

Dielectric strength

- between coil and contacts

- contact clearance

- pole - pole

5 000 V AC

1 000 V AC

2 500 V AC

Electrical life resistive

AC1

>10⁵       8 A, 250 V AC

Mechanical life (cycles)

>3 x 10⁷

Ambient temperature operating

 AC

-40…+70°C;

 DC

-40…+85°C
