Code |
Description |
Model |
Tech. Note |
Manual |
Stock |
|
|
RM3C211 |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 24 Vac - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
 |
 |
|
|
|
RM3C213 |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 115 Vac - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
|
|
 |
|
|
RM3C216 |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 230 Vac - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
|
|
|
|
|
RM3C217 |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 240 Vac - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
|
|
|
|
|
RM3C21H |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 20...150 Vdc/48 Vac - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
|
|
|
|
|
RM3C21L |
Direct current/voltage measuring relay - Format: rail DIN wall mounting - Input: 50...200mV/5...20V/50...200V/0,5...2mA/5...20mA/4...20mA - Output: 2 relays with SPDT contact - Aux: 150...250 Vdc - Alarm threshold: programmable 2 max or 2 min or 1 min + 1 max
|
RM3C |
|
|
|
|
