Oscilloscope Probe 1:1-1:10 - HP-3060 订购编号:
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
Oscilloscope Probe 1:1-1:10 - HP-3060 60 MHz bandwidth, rated 600 V.
The Oscilloscope Probe 1:1-1:10 - HP-3060 is a 1:1-1:10 selectable passive high impedance oscilloscope probe with 60 MHz bandwidth (1:10) designed and calibrated for use on an oscilloscope having an input impedance of 1 MOhm shunted by 20 pF. However, it may be compensated for use with oscilloscopes having an input capacitance of 15 to 35 pF.
The oscilloscope probe incorporates a two position slide switch in the head which selects the attenuation of X1, X10 position.
The modular construction facilitates simple field replacement of the major parts.
Oscilloscope Probe 1:1-1:10 - HP-3060 key specifications
| Oscilloscope Probe 1:1-1:10 - HP-3060 |
|---|
| 1:1 and 1:10 attenuation |
| 5.8 ns rise time |
| 60 MHz bandwidth |
| 600 V CAT I rating |
Models
The following models of the Oscilloscope Probe 1:1-1:10 - HP-3060 are available:
| Order code | |
|---|---|
| HP-3060 |
Package contents
The Oscilloscope Probe 1:1-1:10 - HP-3060 is delivered with:
| Amount | Item |
|---|---|
| 1 | Oscilloscope Probe 1:1-1:10 - HP-3060 |
| 1 | Sprung hook |
| 1 | Ground lead |
| 1 | Insulating tip |
| 1 | IC tip |
| 1 | Measuring tip |
| 1 | BNC adapter |
| Various | Color coding rings |
Oscilloscope Probe 1:1-1:10 - HP-3060 specifications
The table below shows detailed specifications of the Oscilloscope Probe 1:1-1:10 - HP-3060.
| Oscilloscope Probe 1:1-1:10 - HP-3060 - Specification | |
|---|---|
| Max. input voltage | |
| 1:1 | 300 V CAT I / 150 V CAT II (DC + peak AC), derating with frequency |
| 1:10 | 600 V CAT I / 300 V CAT II (DC + peak AC), derating with frequency |
| Input resistance | |
| 1:1 | 1 MOhm oscilloscope input resistance |
| 1:10 | 10 MOhm when used with oscilloscopes which have 1 MOhm input |
| Input capacitance | |
| 1:1 | 128 pF plus oscilloscope capacitance |
| 1:10 | Approx. 23 pF |
| Bandwidth | |
| 1:1 | DC to 6 MHz |
| 1:10 | DC to 60 MHz |
| Rise time | |
| 1:1 | 58 ns |
| 1:10 | 5.8 ns |
| Compensating range | 15 to 35 pF |
| Cable length | 1.4 m (55 inch) |
| Operating temperature | -10 °C to 55 °C |
| Relative humidity | ≤ 85 % (at 35 °C) |
| Safety | meets EN61010-031 CAT II |
| Accessories |
Channel identifier clip Sprung hook Ground lead Insulating tip IC tip Adjusting tool Measuring tip BNC adapter |
Voltage derating curve
