Oscilloscope probe 1:1 - HP-2022 订购编号:
点击这里发送询价请详细填写一下内容，包括产品原产国、品牌完整名称以及您所能得到的所有信息，这将有助于我们准确迅速的报价。非常感谢！
Oscilloscope probe 1:1 - HP-2022 15 MHz bandwidth, rated 600 V.
The Oscilloscope probe 1:1 - HP-2022 is a passive high impedance oscilloscope probe with 15 MHz bandwidth designed and calibrated for use on oscilloscopes having an input impedance of 1 MOhm shunted by 20 pF.
The modular construction facilitates simple field replacement of the major parts.
Oscilloscope probe 1:1 - HP-2022 key specifications
| Oscilloscope probe 1:1 - HP-2022 |
|---|
| 1:1 attenuation |
| 23 ns rise time |
| 15 MHz bandwidth |
| 600 V rating |
Models
The following models of the Oscilloscope probe 1:1 - HP-2022 are available:
| Order code | |
|---|---|
| HP-2022 |
Package contents
The Oscilloscope probe 1:1 - HP-2022 is delivered with:
| Amount | Item |
|---|---|
| 1 | Oscilloscope probe 1:1 - HP-2022 |
| 1 | Sprung hook |
| 1 | Ground lead |
| 1 | Insulating tip |
| 1 | IC tip |
| 1 | Measuring tip |
| 1 | BNC adapter |
| Various | Color coding rings |
Oscilloscope probe 1:1 - HP-2022 specifications
The table below shows detailed specifications of the Oscilloscope probe 1:1 - HP-2022.
| Oscilloscope probe 1:1 - HP-2022 - Specification | |
|---|---|
| Attenuation ratio | 1:1 |
| Max. input voltage | 600V CAT I / 300V CAT II (DC + peak AC), derating with frequency, see below |
| Input resistance | 1 MOhm (oscilloscope input resistance) |
| Input capacitance | 46 pF (plus oscilloscope input capacitance) |
| Bandwidth | DC to 15 MHz |
| Rise time | 23 ns |
| Safety | meets EN61010-031 CAT II |
| Cable length | 1.2 m (47 inch) |
| Accessories |
Channel identifier clip Sprung hook Ground lead Insulating tip IC tip Measuring tip BNC adapter |
Voltage derating curve
