Accessories & Software:
| EK-BUS: | Expandable power supply connector | |
| EK-SUPPLY: | Redundant power supply module for EK-Line modules | |
| EEASY USB: | USB - UART TTL Converter | |
| ES117P-1: | RS232/USB, TTL/USB, RS485/USB Serial Converter | |
| ES107USB: | RS485/USB Serial Converter, Desk Version | |
| EEASY SETUP: | EJH configuration suite (including K111, K120RTD, K121) | |
| EEASY LP: | EJH loop powered instruments configurator (including K120RTD, K121) | |
| Driver USB: | EK107USB & USB interfaces instruments CD driver tool |
EK-BUS
Expandable power supply connector
Each expandable connector K-BUS allows inserting two modules. EK-BUS are inserted on guide setting them to the top and round them at the bottom.
| Order code : | EK-BUS | |
| Description: | Expandable power supply connector | |
| Conformity: | EN 60175 | |
| Inserting modularity: | 2 | |
| Mechanical insert: | laying superior side, bottom rotation | |
| Direct supply: | connection of source (24 Vdc) to instrument terminals | |
| SMART SUPPLY system: | K-BUS Expandable power supply use |
EK-SUPPLY
Redundant power supply module for K-Line modules
SUPPLY SYSTEM. With the exception of loop powered instruments, which aren’t bus powered, K Line signal conditioners can be powered in 3 different ways: by the springcage terminal block (24 Vdc direct from power supply) or by SMART SUPPLY system. SMART SUPPLY system is based on expandable KBUS connector. Up to 16 devices, the distribution of power supply is possible connecting a single device at voltage source, as whole consumption doesn’t exceed 400 mA. Over 16 and up to 75 devices, with maximum current consumption of 1,6 A (approx 21 mA per module), it’s needed K-SUPPLY module that gets overvoltages protections on-board.
| Order code : | EK-SUPPLY | |
| Description: | Redundant power supply module for K-Line modules | |
| Power supply: | 19,2..30 Vdc | |
| Interface 1: | nr 2 inputs with shared negative terminal | |
| Interface 2: | power supply, max voltage drop 300 mV, max current per terminal 4 A | |
| Special functions: | Differential mode filter, integrated protection against overvoltages, connection with redundant power supply, to several bus and parallel inputs |
